LiftMaster 87504 vs 84505R - Which Smart Opener Is Better?

These two models come up constantly when people are replacing openers and asking which LiftMaster to get. Both are belt drive, both have myQ, both are considered premium residential units. The question is what the actual differences are and which one matters for a specific situation.

Here's the direct comparison - what's the same, what's different, and which one to choose.

What's the same on both models

Both are belt drive. Quieter than chain drive, appropriate for attached garages, the right choice when noise matters. The belt drive mechanism is the same class between these two models.

Both use myQ connectivity. Same app, same platform, same Amazon Key integration, same Google Home and Alexa compatibility. From a smart features perspective, the platform experience is identical.

Both use LiftMaster's Security+ 2.0 rolling code technology for remotes and keypads.

Both are professional-grade LiftMaster products - the dealer line, not the consumer retail line. Better build specification than equivalent Chamberlain consumer models.

The 87504 - the integrated battery backup model

The 87504-267 (and its variants) is LiftMaster's integrated battery backup unit. This is the defining feature that separates it from most other openers on the market.

The battery backup is not an add-on module - it's built into the unit. The battery charges automatically from grid power and activates automatically during power outages. The door works normally on battery. And critically - myQ connectivity stays active on battery power. You can still monitor and operate the door via app during a power outage.

This integrated implementation is better than add-on backup modules in two ways. First, the transition from grid to battery is seamless - you don't notice it. Second, the smart connectivity staying active on battery means the full myQ feature set is available during outages, not just mechanical door operation.

The 87504 also has an integrated camera in some configurations (the 87504-267 specifically). The camera mounts on the motor unit and provides a view of the garage interior, recording when the door activates. This is the model that makes Amazon Key in-garage delivery most complete - the delivery is recorded by the same system that manages the access.

HP rating on the 87504: 3/4 HP. Appropriate for most standard residential doors including heavy insulated double doors. For very heavy doors or very high ceilings - the 84505R (below) may have an advantage.

Price range installed: $420-490 for the 87504-267 with camera and backup.

The 84505R - the DC motor high-performance model

The 84505R uses a DC motor rather than the AC motor in the 87504. DC motors have specific characteristics that differ from AC:

Variable speed. DC motors can adjust speed throughout the travel cycle - starting slowly, accelerating through the middle of the travel, and slowing down before hitting the stop at the top and bottom. This is gentler on the door hardware and the opener mechanism. Less impact force on every cycle.

Quieter operation. DC motors run quieter than equivalent AC motors. The 84505R is one of the quietest residential openers available.

Higher HP equivalent. The 84505R is rated at 1 HP (or 1-1/4 HP depending on the variant). For heavy doors - solid wood, very large double doors, commercial-adjacent residential applications - this additional power matters.

Battery backup availability. The 84505R does have battery backup available but it's a separate add-on rather than fully integrated. The myQ connectivity on backup power is more limited than the 87504's integrated backup implementation.

The 84505R also has built-in camera capability with the myQ Smart Garage Camera integration.

Price range installed: $450-530 for the 84505R with camera.

Side by side - the key differences

Battery backup integration: 87504 wins clearly. Fully integrated, myQ stays active on battery, seamless transition. The 84505R backup is add-on and less complete.

Motor type and variable speed: 84505R wins. DC variable speed is genuinely smoother and quieter than AC motor operation. The soft start and stop on each cycle is gentler on the door and hardware over thousands of cycles.

Raw power: 84505R wins for heavy doors. 1 HP+ DC motor has more power for demanding applications.

Noise: 84505R is quieter in operation than the 87504.

Smart features platform: Tie. Both use myQ with the same feature set.

Price: 87504 is typically $30-50 less than the 84505R at comparable configuration.

Which one to choose - the decision framework

Choose the 87504 if: Battery backup is a priority. You're in an area with power outages - storms, grid unreliability, winter outages in cold climates. You want myQ to stay active during outages. You want the integrated camera for Amazon Key delivery tracking. The door is standard weight and the 3/4 HP motor is adequate.

Choose the 84505R if: You have a heavy door that benefits from the higher power rating. You want the absolute quietest operation and the soft start/stop of DC variable speed is important. Battery backup is less critical. The door gets heavy use and the variable speed operation is worth having for long-term hardware longevity.

For most attached garage residential applications with standard to moderately heavy doors in storm-prone areas - the 87504 with its integrated battery backup is the more practical choice. Battery backup utility in real-world use is hard to overstate once you've had a power outage with a car stuck inside.

For a very quiet garage with a heavy door in an area where power outages are rare - the 84505R's DC motor and higher power rating give you a smoother, quieter daily experience.

Both compared to the broader LiftMaster lineup

Both the 87504 and 84505R are at the premium end of LiftMaster's residential lineup. If budget is a consideration, the 8500W (jackshaft) or the 84505 (non-R variant) offer similar features at lower price points with some tradeoffs.

The jackshaft/wall-mount option (LiftMaster 8500W) is worth mentioning - it mounts beside the door rather than on the ceiling, clears the full ceiling for storage, and is very quiet. Different installation than the 87504 or 84505R but worth knowing about for garages where ceiling clearance matters.

For the full smart opener comparison including Chamberlain and Genie alongside LiftMaster, our best smart garage door openers 2026 guide covers the cross-brand landscape. And for battery backup specifically, our battery backup opener guide covers why the integrated implementation in the 87504 specifically stands out.

Installation considerations for both models

Both models require professional installation for best results. The limit calibration, force setting, and balance verification should be done by a tech who will confirm everything is set correctly before leaving.

The camera setup on both models requires WiFi connection and app pairing - confirm the installer completes this and verifies the camera and myQ connectivity before the visit ends. It's faster to do during the installation visit than to troubleshoot later.

For both models, the spring balance should be verified before installation. If the springs are weak, the opener's smart force-sensing won't function accurately because the baseline load is wrong. A balanced door on a well-maintained spring system is the foundation that makes either opener perform as designed.
